AFR 20

Category
Lines for files with tapes and for suspension files

AFR 20

LINES FOR FILES WITH TAPES AND FOR SUSPENSION FILES

Automatic line for assembling files having 6 tapes (fastened by metal eyelets), supplied with flat creasing unit.

Technical features

Material: Coated board, Fiber board or similar – Auto-punching eyelets standard range – Tape in reels
Cardboard thickness:
1 mm to 3 mm
Capacity:
up to 15 cycles/minute
Electrical power req.:
7 Kw
Compressed air:
500 NL/min. (pressure 7 bar)
Overall dimensions:
L= 5800mm W=4300mm H= 2100mm
