Half-automatic machine for assembling folders with flat criss-cross elastic band fastened by metal eyelets.
– coated board
– fiber board or polypropelene- eyelets and/or rivets standard range
– elastic flat band 5 mm wide
Cardboard thickness: 1 mm up to 2,5 mm
Capacity: up to 8 pieces/min.
Electrical power req.: 3 Kw
Compressed air: 350 NL/min. (pressure 7 bar)
Overall dimensions: L=2000mm W=1800mm H=1900mm
