CORD-R

METAL EDGING AND LEVER-ARCH FILE ASSEMBLING LINES

Automatic machine for multiple creases with upwards creasing unit, supplied with board feeding unit.

Technical features

Material: Coated board, Fiber board or similar
Cardboard thickness:
1 mm up to 3,5 mm
Capacity:
up to 30 cycles/minute (with 2 creases)
Optionals:
Soft board blade (min. 200 gr/sqm)
Heated blade for PP (Thickness min. 0,5 mm)
Electrical power req.:
3 Kw
Compressed air:
50 NL/min. (pressure 7 bar)
Overall dimensions:
L=3200 mm W=1210mm H=1350mm
